Hydraulic Roll Grooving Machine for 1 Inch to 12 Inch Ideal for Distributors(RG-5X)
- Model
- RG-5X
Item specifics
- Fabrication Capacity
- 1"-8" SCH10/40 ;10"-12" SCH10/20
- Max Wall Thickness
- 8mm
- Output Speed
- 23RPM
- Power Supply
- 1100W
- Packing Size
- 75*40*70cm
- Gross Weight
- 118KG
Review
Description
Pipe Roll Grooving Machine Video
Features of Electric Hydraulic Roll Groover Machine
● Model RG-5X Electric Hydraulic Roll Grooving Machine is designed to roll grooves on steel pipes and stainless steel from 1"-8" SCH10/SCH40, 12"-12" SCH10/SCH20.
● Suitable for a wide range of everyday tasks related to fire-fighting pipes, this roll groover is a versatile tool equipped with a motor, hydraulic feeding pump, foot switch, and pipe stand.
● The built-in high-performance gear reduction system of the motor allows for a more compact design and lower levels of noise.
● The unique combination of the hydraulic feeding pump and the groove depth lock knob guarantees premium grooves and optimal efficiency.
● The roll grooving machine is equipped with a frame and swivel wheels for easy movement and transport.
Pipe Roll Grooving Machine Parameter
Model: | RG-5X |
Suitable materials: | Carbon Steel,SS Pipe |
Fabrication Capacity: | 1"-8" Pipe SCH10/SCH4010"-12" Pipe SCH10/SCH20 |
Power supply: | 220V/110V |
Frequency: | 50HZ /60HZ |
Max wall thickness: | 8mm |
Motor power: | 1100W |
Output speed: | 23RPM |
Packing gross weight: | 118kgs |
Packing size: | 75*40*70cm |
Standard Parts of RG-5X Roll Groover
Item Number | Description | Net weight | ||||
911106 | Drive roller 1"-1 1/2"(φ33-φ48) | 1.15kg | ||||
911007 | Drive roller 2"-3"(φ60-φ89) | 1.15kg | ||||
911008 | Drive roller 3 1/2"-6"(φ101-φ168) | 1.70kg | ||||
911019 | Drive roller 8"-12" (φ219-φ325) | 1.70kg | ||||
912041 | Groove roller 1"-1 1/2"(φ33-φ48) | 0.90kg | ||||
912042 | Groove roller 2"-6"(φ60-φ168) | 0.80kg | ||||
912043 | Groove roller 8"-12" (φ219-φ325) | 0.70kg | ||||
998078 | Pipe stand | 6.90kg | ||||
998033 | Pipe Stabilizer | 2.80kg | ||||
998026 | Foot Switch | 1.50kg | ||||
Drive Unit of RG-5X Roll Groover
Catalog No. | Phase | Power | Voltage | Frequency |
900050 | Single | 1100W | 220V | 50/60Hz |
900051 | Single | 1100W | 110V | 50/60Hz |
Resources of RG-5X Roll Grooving Machine
Roll Grooving Machine Configuration
Hydraulic pump
High quality seal parts ensure long-term field usage without leaking
Fine-machined cylinder with accurate sizes
Proper-hardened piston rod of long-life
Built-in groove depth adjusting rod
Casting part
Reinforced cast iron housing for hydraulic pump, roller sets, pipe stabilizer
Support color customization
Balanced structure withstands tough jobs
Base & Parts
Pipe stabilizer ① to prevent pipe slipping; Steel tube bracket ② for handy grip
Complete steel base plate ③ High-strength, solid and deformation-resistant. Tool box ④ for easy stock of roll sets, tools and parts
Tooll box
Can put the groove roller and drive roller ,π tape and other small wrenches
Roll Sets
Available in sizes:1"-1 1/2", 2"-3",2"-6",8"-12"
For Steel pipe 1"-8",Pipe SCH10/SCH40;10"-12",Pipe SCH10/SCH20
High strength steel, hardened to withstand long-time usage
Pipe Stand
Quick size adjustable rods, fine-machined slots with latch
Steel ball heads,for smooth rotation,forward-backward moving of pipe
Adjustable height to suit different size pipes:1"-12"
Foot Switch
Pipe Stablizer
